Key Highlights
-
Capacity: 75,000 lb
-
Alloy steel construction for rugged durability
-
Hermetically sealed, IP68 rating for maximum protection in harsh environments
-
Output options: 2–10 mA (PN 115199, PN 151456) or 2–20 mA (PN 169221)
-
Wide operating temperature: 14 °F to 104 °F (-10 °C to 40 °C)
-
High insulation resistance: 2,000 MΩ at 50 VDC
-
Dual 5-pin Turck Minifast connectors for secure connectivity
-
Backed by a one-year limited warranty
The RLPLS-75K load cell is a high-capacity, hermetically sealed sensor engineered for heavy-duty weighing applications requiring extreme durability and precision. Built from alloy steel and sealed to IP68 standards, this load cell ensures long-lasting performance even in wet, dusty, or industrially harsh environments.
With 75,000 lb capacity, the RLPLS-75K offers reliable mA current loop outputs with options of 2–10 mA or 2–20 mA, providing flexibility for different system requirements. Its dual Turck 7/8 in Minifast, 5-pin connectors deliver strong, stable connections that integrate easily into existing weighing systems.
Designed for industrial platforms, truck scales, and custom heavy-load applications, this load cell ensures accurate measurements with rigid reliability and low maintenance requirements.
Specifications
| Feature |
Details |
| Capacity |
75,000 lb |
| Material/Finish |
Alloy steel |
| Output |
2–10 mA (PN 115199, PN 151456) / 2–20 mA (PN 169221) |
| Temperature Range |
14 °F to 104 °F (-10 °C to 40 °C) |
| Insulation Resistance |
2,000 MΩ at 50 VDC |
| Seal Type |
Hermetically sealed, IP68 |
| Connector Type |
Turck 7/8 in Minifast, 5-pin (x2) |
| Connector Pin Out |
Pin 1: Loop Power / Pin 2: Current Loop / Pin 3: Shield / Pin 4: NC / Pin 5: Ground |
| Warranty |
One-year limited |
Applications
-
Truck scales and axle weighing systems
-
Heavy industrial platforms
-
Construction and mining equipment
-
Custom heavy-load force measurement
The RLPLS-75K Alloy Steel Load Cell delivers precision, strength, and long-term durability for the most demanding industrial weighing systems. With hermetic sealing, IP68 protection, and high-capacity output, it is built to perform in the toughest environments.
Contact us today to request a quote or learn how the RLPLS-75K can improve your heavy-duty weighing applications.
