Key Highlights
-
Heavy-Duty Load Capacity: 2.5-inch alloy steel load pin with 20,000 lb capacity.
-
Rugged Construction: Built with durable alloy steel for long-lasting industrial use.
-
Environmentally Sealed: Protected against harsh environments for dependable operation.
-
Reliable Output: 1.3 mV/V full scale with stable input and output resistance.
-
Simple Connectivity: Equipped with Turck M12 4-pin male connector for easy integration.
-
Wide Application Range: Ideal for heavy industrial, transportation, and load monitoring systems.
The Load Pin – 2.5 Inch, 20K Alloy Steel is engineered for demanding load monitoring applications, offering both strength and precision. Designed with alloy steel construction and an environmentally sealed enclosure, this load pin delivers reliable performance in rugged industrial and outdoor environments.
With a 20,000 lb capacity and 1.3 mV/V full-scale output, it provides accurate and consistent results for weighing, monitoring, and structural load applications. Its 350-ohm input and output resistance ensures stable operation across a wide range of conditions.
The Turck M12 4-pin male connector allows for simple and secure installation, while the environmentally sealed design ensures long-lasting reliability in environments exposed to moisture, dust, or dynamic forces.
Whether used in transportation, logistics, heavy machinery, or structural monitoring, this load pin provides a dependable and rugged solution for industrial load measurement.
Specifications
| Feature |
Specification |
| Capacity |
20,000 lb |
| Pin Size |
2.5 inch |
| Full Scale Output |
1.3 mV/V |
| Output Resistance |
350 ohm (nominal) |
| Input Resistance |
350 ohm (nominal) |
| Material/Finish |
Alloy steel |
| Temperature Range |
14 °F to 104 °F (-10 °C to 40 °C) |
| Rated Excitation |
15 VDC (5–10 V recommended) |
| Insulation Resistance |
500 megohms at 50 VDC |
| Seal Type |
Environmentally sealed |
| Connector Type |
Turck, M12 4-pin male |
| Warranty |
One-year limited warranty |
Connector Pin Out
| Pin |
Function |
| Pin 1 |
Excitation + |
| Pin 2 |
Signal + |
| Pin 3 |
Excitation – |
| Pin 4 |
Signal – |
Upgrade your load monitoring system with the Load Pin – 2.5 Inch, 20K Alloy Steel. Engineered for strength, accuracy, and durability, this load pin is the perfect choice for heavy-duty weighing and industrial applications.
Request a quote today to enhance your operation with proven reliability.
