Key Highlights
-
High capacity: 125,000 lb heavy-duty load cell
-
Alloy steel construction: For superior strength and durability
-
Environmentally sealed to IP66: For dependable outdoor and industrial use
-
2–20 mA output: For stable signal transmission in demanding conditions
-
Turck 7/8 in Minifast: 5-pin connector for secure connectivity
-
Wide temperature range: 14 °F to 104 °F (-10 °C to 40 °C)
-
High insulation resistance: 2,000 MΩ at 50 VDC
-
Protected with a one-year limited warranty
The RLPLS-125K-mA load cell is engineered for ultra-heavy-duty weighing applications where durability, reliability, and precise measurement are critical. Constructed from alloy steel and environmentally sealed to IP66 standards, this load cell resists dust, water spray, and harsh working environments, making it ideal for outdoor and industrial operations.
With its 125,000 lb capacity, the RLPLS-125K-mA provides a 2–20 mA output signal, ensuring consistent and interference-resistant communication over long distances. Its Turck 7/8 in Minifast, 5-pin connector allows quick integration into new or existing weighing systems.
This rugged load cell is designed for truck scales, large platform scales, and custom heavy-load applications, ensuring maximum uptime and dependable performance.
Specifications
| Feature |
Details |
| Capacity |
125,000 lb |
| Material/Finish |
Alloy steel |
| Output |
2–20 mA |
| Temperature Range |
14 °F to 104 °F (-10 °C to 40 °C) |
| Insulation Resistance |
2,000 MΩ at 50 VDC |
| Seal Type |
Environmentally sealed, IP66 |
| Connector Type |
Turck 7/8 in Minifast, 5-pin |
| Connector Pin Out |
Pin 1: Loop Power / Pin 2: Current Loop / Pin 3: Shield / Pin 4: NC / Pin 5: Ground |
| Warranty |
One-year limited |
Applications
-
Truck and axle scales
-
High-capacity industrial platforms
-
Mining, logging, and construction equipment
-
Custom heavy-duty load measurement systems
The RLPLS-125K-mA Alloy Steel Load Cell combines exceptional capacity, rugged construction, and reliable 2–20 mA output to deliver precision and durability in extreme environments.
Contact us today to request a quote or discuss how the RLPLS-125K-mA can enhance your heavy-duty weighing applications.
