Wireless RF Display – 2.4 GHz spread-spectrum communication for real-time data
Large LED Digits – 6-digit, long-life, high-intensity red LEDs in 4 in or 6 in size
IP66 Weather-Tight Enclosure – Built for rugged outdoor and industrial environments
Integrated Repeater – Ensures data reach and reliability over longer distances
Multiple Mounting Options – Tilt bracket, flat-wall (VESA), or side-mount flange
Auto Learn Protocols – Self-configuring with compatible MSI products
Day/Night Modes – Software-selectable brightness for visibility in all conditions
Echo Output – RS-232 output for data echoing to secondary devices
Mirror Mode – Reverse image functionality for operator convenience
Compatible with All MSI ScaleCore™ Systems – Including crane scales, indicators, and RF displays
The MSI Wireless RF Scoreboards are engineered to provide bold, real-time weight visibility in dynamic, industrial applications. Featuring six-digit high-intensity LED displays (available in 4-inch and 6-inch heights), these scoreboards are the ideal complement to MSI crane scales, remote indicators, and tension dynamometers.
Each scoreboard includes an integrated 2.4 GHz RF transceiver, ensuring seamless compatibility with a wide range of MSI products including the MSI-7300 Dyna-Link 2, MSI-3460 Challenger 3, MSI-4260 Port-A-Weigh, MSI-7000 / 7001 TranSend™, and remote displays like the MSI-8000HD and MSI-8004HD.
With Auto Learn mode, setup is virtually plug-and-play—automatically detecting communication protocols from the paired device. Additional features such as Hold Display Mode, Standstill Mode for no updates in motion, and Mirror Image Output provide user-centric control and safety.
Built to thrive in outdoor and industrial environments, the scoreboard is enclosed in a durable, NEMA 4 / IP66-rated weather-tight housing with a non-glare contrast lens and polyethylene breather vent to prevent moisture build-up. It also features auto-sensing AC/DC power, day/night brightness control, and multiple communication ports including RS-232, RS-485, and 20 mA loops.
| Feature | Details |
|---|---|
| Display Type | Six-digit LED (4 in or 6 in digit height) |
| LED Type | Double-row, high-intensity, discrete red LEDs |
| RF Communication | 2.4 GHz Direct Sequence Spread Spectrum (DSSS) |
| RF Range | 100–300 ft (line of sight); longer range available upon request |
| Enclosure Rating | NEMA Type 4, IP66 weather-tight aluminum enclosure |
| Brightness Control | Adjustable for day/night visibility; software selectable |
| Mounting Options | Tilt bracket (included), VESA PEMs, optional side flange |
| Echo Output | RS-232 serial port |
| Standard Antenna | 1/2 wave, 2 dBi articulated antenna |
| Power Supply | Auto-sensing 85–265 VAC (47–440Hz) / 130–300 VDC |
| Communication Ports | RS-232, 20 mA loop, RS-485 |
| Compatible Devices | MSI-7300, 3460, 4260, 7000, 7001, 8000HD, 8004HD, 9600HT, 6360 |
| Operating Temp Range | -40 °F to 120 °F (-40 °C to 49 °C) |
| Warranty | One-year limited warranty |
| Label | Imperial (in) | Metric (mm) |
|---|---|---|
| A | 22.28 in | 565 mm |
| B | 10.96 in | 280 mm |
| C | 3.28 in | 85 mm |
| D | 9.80 in | 250 mm |
| Label | Imperial (in) | Metric (mm) |
|---|---|---|
| A | 30.63 in | 780 mm |
| B | 13.94 in | 355 mm |
| C | 3.73 in | 95 mm |
| D | 12.77 in | 325 mm |
Need superior visibility in your crane or overhead weighing operation?
The MSI Wireless RF Scoreboard delivers instant, high-contrast weight readings in both indoor and outdoor settings. Whether mounted on a crane or on the production floor, it’s a powerful tool for enhancing operator awareness and workflow safety.
Order now or contact us to integrate the MSI scoreboard into your system.
