The EL204 Signal Trim Junction Box is an ideal solution for floor, hopper, tank, or livestock scales requiring the summing and trimming of two to four load cells. Designed for durability, the ABS enclosure features molded-in watertight cable fittings, a six-screw lid for secure sealing, and a die-cut gasket for dependable environmental protection.
This cost-effective, compact unit is equipped with spring clamp connectors for quick installation and individual signal trimming to fine-tune each load cell's output.
ABS Sealed Enclosure
Molded-in cable fittings and secure six-screw lid for a tight seal.
Supports 2 to 4 Load Cells
Accommodates floor, tank, hopper, and livestock weighing applications.
Tool-Free Spring Clamp Connectors
Easily connect 12 to 28 AWG wires without a screwdriver.
Signal Trim for Each Cell
Precisely balance load cell outputs for accurate measurement.
Floor Scales
Hopper and Tank Weighing
Livestock Scales
General Industrial Environments
| Feature | Details |
|---|---|
| Cable Fittings | (5) Watertight nylon compression fittings (0.210 × 0.280 in) |
| Enclosure | ABS with molded through-fittings and six-screw lid |
| Connectors | Spring clamp, screwless, 12 to 28 AWG |
| Trimming | Individual cell signal trim |
| Potentiometers | 100,000 ohm, 25-turn cermet |
| Circuit Board Size | 3.8 × 2.3 in with conformal coating |
| Operating Temperature | 0 °F to 122 °F (–18 °C to 50 °C) |
| Number of Cells | Two, three or four |
| Warranty | One-year limited |
| Model | Complete J-Box Replacement | Replacement Board Only | Replacement Cord Grips | Replacement Pressure & Condensation Vent | Desiccant Packs |
|---|---|---|---|---|---|
| JB4SS | 88956 | 88958 | 58983=PG7, 59001=PG11 | 88733 PreVent™ breather (vent), 88734 (vent nut) | 92240 |
| JB4ES | 91779 | 89446 | 58983=PG7, 59001=PG11 | 88733 PreVent™ breather (vent), 88734 (vent nut) | 92240 |
| JB4SP / JB4SPT | 91780 / 92762 | 88958 / 89894 | 58983=PG7, 59001=PG11 | 88733 PreVent™ breather (vent), 88734 (vent nut) | 16039 |
| JB4EP / JB4EPT | 91781 / 92763 | 89446 / 89894 | 58983=PG7, 59001=PG11 | 88733 PreVent™ breather (vent), 88734 (vent nut) | 16039 |
| EL204 | 73428 | 88958 | N/A | N/A | N/A |
| JB8SP | 91782, 173807 - FM Approved | 89889, 172415 - FM Approved | 15655 (cord grip), 15656 (nut)=3/8" NPT, 15628 (cord grip), 15630 (nut)=1/2" SPT | 88733 PreVent™ breather (vent), 88734 (vent nut) | 16039 |
| JB8SPT | 91783 | 89889 (load cell), 89894 (transient protection) | 15655 (cord grip), 15656 (nut)=3/8" NPT, 15628 (cord grip), 15630 (nut)=1/2" SPT | 88733 PreVent™ breather (vent), 88734 (vent nut) | 16039 |
| EL304A | 21169 | 21301 | N/A | N/A | N/A |
| JB1010 | 36231 | 36351 | N/A | N/A | N/A |
| JB1010ST | 68813 | 68811 | N/A | N/A | N/A |
| EL210 | 91781, JB4EP* | 92472 | 58983=PG7, 59001=PG11 | N/A | N/A |
| EL211A | 91780, JB4SP* | 92473 (no section trim) | 58983=PG7, 59001=PG11 | N/A | N/A |
| EL604-AL | 88956, JB4SS* | 88958 | 58983=PG7, 59001=PG11 | N/A | N/A |
| EL604STA | 88956, JB4SS* | 88958 | 58983=PG7, 59001=PG11 | N/A | N/A |
| EL604ETA | 91779, JB4ES* | 89446 | 58983=PG7, 59001=PG11 | N/A | N/A |
| EL504 | 21165 | 21296 | N/A | N/A | N/A |
| JB808S | 91782, JB8SP* | 92471 | 15655 (cord grip), 15656 (nut)=3/8" NPT, 15628 (cord grip), 15630 (nut)=1/2" SPT | N/A | N/A |
| JB818ST | 91783, JB8SPT* | Need (1) 77445, 89889, 89894 | 15655 (cord grip), 15656 (nut)=3/8" NPT, 15628 (cord grip), 15630 (nut)=1/2" SPT | N/A | N/A |
