1 in (25 mm) LCD with backlight for low-light environments
Available in 3 enclosure types: FRP, stainless steel, compact, or panel mount
Four annunciators: lb, kg, gross, net
Compatible with most digital weight indicators via RS-232 and current loop
Intuitive data receiver automatically interprets serial strings
Reliable AC operation, with DC voltage flexibility
NEMA Type 4X protection for harsh industrial conditions
Simple installation with built-in mounting tabs
The Rice Lake RD-300 is a dependable, compact remote display designed to clearly present weight data in demanding indoor environments. Its 1-inch LCD display with built-in backlight ensures high readability, even in poorly lit areas such as warehouses, production lines, or logistics hubs.
Housed in a rugged fiberglass-reinforced polyester (FRP) or stainless steel enclosure, the RD-300 is built for durability and visibility. The unit features status annunciators for gross, net, lb, and kg—perfect for diverse applications. It also includes RS-232 and 20 mA loop interfaces, making it plug-and-play with most digital indicators.
This remote display simplifies weight monitoring without sacrificing reliability or clarity, making it an essential accessory for any industrial weighing system.
| Feature | Details |
|---|---|
| Display | 6-digit, 7-segment, 1 in (25 mm) LCD with backlight |
| Annunciators | lb, kg, gross, net |
| Operating Voltage | 115 VAC, 230 VAC available; 6.2 to 18 VDC |
| Input Interface | RS-232, 20 mA current loop (active/passive) |
| Baud Rate | 300 – 19200 (Selectable) |
| Temperature Range | -13 °F to 104 °F (-25 °C to 40 °C) |
| Enclosure Options | FRP, Stainless Steel, Compact, Panel Mount |
| Weight | 5 lb (FRP), 8 lb (Stainless Steel) |
| Warranty | One-year limited |
| Label | Measurement |
|---|---|
| A | 8.00 in (203 mm) |
| B | 9.50 in (241 mm) |
| C | 6.00 in (133 mm) |
| D | 4.00 in (101 mm) |
| E | 8.75 in (222 mm) |
| Label | Measurement |
|---|---|
| A | 8.00 in (203 mm) |
| B | 10.00 in (254 mm) |
| C | 4.31 in (109 mm) |
| D | 8.63 in (219 mm) |
| E | 8.00 in (203 mm) |
| Label | Measurement |
|---|---|
| A | 6.25 in (158 mm) |
| B | 9.25 in (234 mm) |
| C | 2.00 in (50 mm) |
| D | 5.25 in (133 mm) |
| E | 8.50 in (215 mm) |
| Label | Measurement |
|---|---|
| A | 5.88 in (149 mm) |
| B | 7.88 in (200 mm) |
| C | 2.00 in (50 mm) |
| D | 5.12 in (130 mm) |
| E | 7.12 in (180 mm) |
