Key Highlights
-
25,000 lb Capacity: Designed for demanding onboard weighing applications.
-
Premium Stainless Steel: Provides corrosion resistance and long-lasting durability.
-
Hermetically Sealed: IP69 rating ensures maximum protection against dust, water, and harsh environments.
-
Reliable Output: Delivers a stable 2.0 mV/V full scale signal.
-
High Insulation Resistance: 5,000 megohms at 50 VDC for superior electrical reliability.
-
Wide Industrial Use: Ideal for onboard weighing, transport, and heavy-duty load monitoring systems.
The PL9200-25K Stainless Steel Load Cell is engineered for onboard weighing applications that require high accuracy, durability, and resistance to harsh environments. Constructed from premium stainless steel and rated IP69, this hermetically sealed load cell provides complete protection against moisture, dust, and extreme weather conditions.
With a 25,000 lb capacity and 2.0 mV/V full scale output, the PL9200 delivers consistent and precise performance. Its high insulation resistance of 5,000 megohms ensures reliable signal integrity, while the ±0.25% non-linearity guarantees dependable measurement accuracy.
The 25 ft cable length offers installation flexibility, making it suitable for a wide range of onboard and mobile weighing systems. Whether used in trucking, logistics, or heavy equipment monitoring, the PL9200-25K provides unmatched durability and reliability.
Specifications
| Feature |
Specification |
| Capacity |
25,000 lb |
| Full Scale Output |
2.0 mV/V |
| Output Resistance |
700 ohm (nominal) |
| Input Resistance |
736 ohm (nominal) |
| Material/Finish |
Stainless steel |
| Temperature Range |
14 °F to 104 °F (-10 °C to 40 °C) |
| Rated Excitation |
15 VDC (5–10 V recommended) |
| Non-linearity |
±0.25% full scale |
| Insulation Resistance |
5,000 megohms at 50 VDC |
| Seal Type |
Hermetically sealed, IP69 |
| Cable Length |
25 ft |
| Warranty |
5-Year limited |
Wire Color Code
| Wire |
Function |
| Red |
+Excitation |
| Black |
-Excitation |
| Green |
+Signal |
| White |
-Signal |
| Yellow |
Shield |
Enhance your onboard weighing system with the PL9200-25K Stainless Steel Load Cell. Built to withstand the harshest conditions, it ensures long-term accuracy and reliability for transport and industrial operations.
Order now or request a quote today to experience unmatched performance and durability.
