Key Highlights
-
Specifically designed for fifthwheel kits and spring suspension equalizer hangers
-
Dual bearing plate design for secure mounting and stability
-
2.8-inch profile provides low-clearance installation flexibility
-
Hermetically sealed to IP68 for full protection against water and dust
-
±0.1% full scale non-linearity for highly accurate weighing results
-
Rugged alloy steel construction ensures long-lasting durability
-
Conxall 4-pin connector with standard pin-out for simple setup
-
Backed by a one-year limited warranty
The PL9000-50 Load Cell is engineered to deliver precise and reliable performance in demanding onboard weighing applications. Its specialized design makes it an excellent fit for fifthwheel kits and spring suspension equalizer hangers, where robust load sensing is essential.
Featuring two separate bearing plates—one on each end—the PL9000-50 ensures secure load distribution and structural stability. Its 2.8-inch profile allows integration into tight spaces without compromising performance. Built from rugged alloy steel and hermetically sealed to IP68, this load cell offers superior resistance to moisture, dirt, and environmental challenges, guaranteeing consistent operation in the harshest conditions.
Delivering an output of 0.25 mV/V at 12,500 lb, the PL9000-50 ensures precise measurement, while its ±0.1% full scale non-linearity provides the accuracy required for commercial and industrial weighing systems. The Conxall 4-pin connector simplifies installation, with a reliable pin-out configuration for quick integration.
Ideal for heavy-duty vehicle weighing systems, the PL9000-50 combines strength, accuracy, and durability, making it a trusted choice for fleet operators and scale manufacturers alike.
Specifications
| Feature |
Details |
| Output |
0.25 mV/V at 12,500 lb |
| Output Resistance |
350 Ω (nominal) |
| Input Resistance |
350 Ω (nominal) |
| Material/Finish |
Alloy steel |
| Temperature Range |
14 °F to 104 °F (-10 °C to 40 °C) |
| Rated Excitation |
15 VDC (5–10 V recommended) |
| Non-linearity |
±0.1% full scale |
| Insulation Resistance |
500 megohms at 50 VDC |
| Seal Type |
Hermetically sealed, IP68 |
| Cable Length |
32 in cable |
| Connector Type |
Conxall, 4-pin (male) |
| Connection Pin Out |
A - Excitation +
B - Signal +
C - Signal -
D - Excitation - |
| Warranty |
One-year limited |
The PL9000-50 Alloy Steel Load Cell is the ideal solution for fifthwheel kits and spring suspension systems, delivering precision, durability, and IP68-rated protection for reliable performance in challenging environments.
Contact us today to request pricing, technical details, or assistance with integrating the PL9000-50 into your onboard weighing system.
