SL-800 NTEP Floor Scale – Build Your Own (Imported)

The SL-800 is our NTEP certified floor scale, legal for trade, for businesses that sell or ship by weight. Choose from twelve platform sizes from 2' x 2' to 7' x 7' and capacities from 1,000 to 20,000 lb.

Key features

• Legal for trade. NTEP certified base (certificate 22-056) and indicator (certificate 22-027).
• Built for daily use. Welded steel platform with a smooth or diamond plate deck.
• Protected against overloads. 200% overload protection helps the load cells last.
• Clear 1 inch display. The SL-7510 indicator comes with LCD or LED, in painted or stainless steel.
• Ready to connect. Full duplex RS-232 for printers, scoreboards and computers.

Sizes and capacities

Every platform size comes in all five capacities. Pick both in the drop downs above.

Specifications

• Platform: Welded steel, smooth or diamond plate deck
• Certification: NTEP, Class III, base certificate 22-056, indicator certificate 22-027
• Overload protection: 200% of capacity
• Indicator display: 1 in, 6-digit LCD with backlight or LED
• Indicator housing: Painted steel, stainless steel or IP67 washdown stainless steel
• Units: lb and kg; oz and g on LCD models
• Functions: Gross, tare, preset tare, zero, hold, counting and accumulation
• Alarms: Overload, underload and error warning
• Output: Full duplex RS-232; remote display and printer ready
• Power: AC adapter included, 100 to 240 V AC; battery optional
• Operating temperature: 14 to 104 °F (-10 to 40 °C)
• Cable: 20 ft heavy-duty metal shielded

In the box

• SL-800 platform in the size you choose
• SL-7510 indicator with AC adapter
• 20 ft shielded indicator cable

Upgrades and add-ons

• Printer. Print a ticket for every weight.
• Scoreboard. A large remote display, in six sizes, for reading from a distance.
• Data software. Keep weight records on your computer.
• Pit frame. Set the scale flush with the floor, permanent or portable.
• Ramps. Roll carts and pallet jacks on and off safely.
• Indicator stand. Holds the indicator at a comfortable height.
• Bumper guards. Shield the platform from forklift hits.
• Analog output. 4-20 mA or 0-5 V to connect to your control system.
• Explosion-proof indicator. The SL-7510-SS-C-EX for hazardous areas.
• Water-resistant upgrade. For damp, humid or rainy locations.

Custom manufacturing

Need a size or material that is not listed? We build scales to custom sizes in carbon steel, galvanized steel, stainless steel and aluminum. Request a quote and tell us what you weigh.

Note: outdoor and wet areas

The standard SL-800 is not waterproof. For outdoor use, choose a stainless steel indicator, stainless steel load cells and a stainless steel junction box, or add the water-resistant upgrade.
