Key Highlights
-
Capacity Range: From 500 kg to 300 tons
-
Material: Zinc-plated mild steel, designed for durability and cost-efficiency
-
Dummy Mount Function: Enables installation of vessel without load cell
-
Built-in Safety Features: Includes lift-off protection and constrainers for lateral force control
-
Patent Pending: Design registered under DE 101 38 435A1
-
GL Certified: Germanischer Lloyd Certificate No. 47-458-03HH
-
High Resistance: 45 kN destructive lateral force; 20 kN permissible lift-off and lateral force
-
Maintenance-Free Design: Self-contained module with no service required
-
Load Cell Compatibility: Optimized for Inteco load cells, 10,000 division, 1 mV/V output
-
Warranty: Industry-leading 15-year load cell warranty
The Minebea Intec Inteco Zinc-Plated Steel Star Mount Kits are robust, precision-engineered mounting kits designed specifically for the Inteco load cell family. With a broad capacity range from 500 kg up to 300 metric tons, these star mounts offer outstanding stability and safety in industrial tank and vessel weighing applications.
A unique feature is the dummy function, which allows users to install and position the tank or vessel before load cells are mounted. The top load disc remains securely in place, enabling a seamless upgrade or delayed installation of the load cells without realignment.
These mounts feature an integrated lift-off protection mechanism and maintenance-free constrainers to withstand high lateral forces — up to 45 kN destructive and 20 kN permissible. The kits meet the safety standards required for heavy-duty industrial environments and are certified by Germanischer Lloyd, ensuring both quality and compliance.
Specifications
| Feature |
Details |
| Material |
Zinc-plated mild steel |
| Load Cell Output |
1 mV/V |
| Capacity Range |
500 kg to 300,000 kg (0.5 to 300 tons) |
| Dummy Mount Feature |
Yes, allows installation without load cell |
| Lateral Force Protection |
45 kN destructive; 20 kN permissible |
| Lift-Off Protection |
Integrated, 20 kN |
| Constrainer |
Maintenance-free |
| Approvals |
Germanischer Lloyd No. 47-458-03HH |
| Patent |
DE 101 38 435A1 |
| Warranty |
15 years (load cell only) |
| Resolution |
10,000 divisions |
| Compatible Load Cell |
Minebea Intec Inteco series |
Applications
-
Tank and silo weighing
-
Batching and mixing systems
-
Vessel weighing in food, chemical, and pharma industries
-
Industrial process control with high lateral force exposure
Upgrade your vessel or tank weighing systems with the Minebea Intec Inteco Star Mount Kits — engineered for safety, precision, and durability. With unmatched lateral force protection, built-in dummy functionality, and a 15-year warranty, these mounts ensure long-term reliability in even the harshest industrial settings.
Contact us today to configure your ideal weighing solution.
