The EL168 1-Cell Junction Splice Box provides an efficient, no-solder solution for extending or splicing load cell cables. Designed with a rugged PVC enclosure and separate input/output cable fittings, this splice box is ideal for single-load-cell systems that require a clean and secure connection in tight or protected environments.
Non-Metallic PVC Housing
Durable and corrosion-resistant for general industrial use.
Solder-Free Installation
No need for compression fittings or swaged terminals.
Strain-Relief Cable Fittings
Protects cable integrity by minimizing stress on connections.
Simple Terminal Block
Seven-position screw terminal accepts up to #16 AWG wire.
Extending load cell cable in single-cell systems
Splicing damaged or shortened cables
Ideal for protected environments in industrial weighing
| Parameter | Details |
|---|---|
| Dimensions (L×W×H) | 4.0 × 4.0 × 2.5 in |
| Operating Temp | 0 °F to 122 °F (-18 °C to 50 °C) |
| Cable Diameter Range | 0.079 to 0.314 in (2 to 8 mm) |
| Terminal Block Rating | 300 V / 15 A – 7-position screw terminals |
| Cable Fittings | Nylon waterproof strain-relief |
| Material | Non-metallic PVC |
| Warranty | One-year limited |
