Key Highlights
-
Capacity: 25,000 lb
-
Rigid double-ended shear beam design for high stability under dynamic forces
-
Compatible with Rice Lake twist-lock and stacking cone mount assemblies
-
Alloy steel construction for strength and durability
-
IP66 environmental sealing protects against dust and moisture
-
High insulation resistance: 2,000 MΩ at 50 VDC
-
Available with 20 ft or 50 ft cable lengths for installation flexibility
-
Backed by a one-year limited warranty
The PLSB-25K load cell is a rigid mount, double-ended shear beam specifically designed for demanding industrial applications. Commonly used in Rice Lake’s twist-lock and stacking cone mount assemblies, it is the ideal solution for systems where a series of mounts are not permanently fixed to a frame.
Thanks to its robust alloy steel construction, the PLSB-25K ensures long-term performance in environments with dynamic forces and challenging conditions. The IP66 environmental sealing offers strong protection from dust and water jets, making this load cell suitable for outdoor or industrial use.
With output resistance of 722 Ω and input resistance of 700 Ω, it provides reliable and consistent measurement accuracy. The PLSB-25K is offered with 20 ft or 50 ft shielded cable options for easy integration into a wide range of weighing systems.
This load cell is a trusted choice for industrial weighing systems, truck scales, and other heavy-duty applications that demand accuracy and resilience.
Specifications
| Feature |
Details |
| Capacity |
25,000 lb |
| Output Resistance |
722 Ω (nominal) |
| Input Resistance |
700 Ω (nominal) |
| Material/Finish |
Alloy steel |
| Temperature Range |
14 °F to 104 °F (-10 °C to 40 °C) |
| Rated Excitation |
15 VDC (5–10 V recommended) |
| Non-linearity |
±0.25% full scale |
| Insulation Resistance |
2,000 MΩ at 50 VDC |
| Seal Type |
Environmentally sealed, IP66 |
| Cable Length Options |
20 ft (PN 179827) / 50 ft (PN 191898) |
| Wire Color Code |
Green = Signal +, White = Signal -, Black = Excitation, Drain Wire = Shield |
| Warranty |
One-year limited |
Applications
-
Rice Lake twist-lock and stacking cone mount assemblies
-
Systems with dynamic force applications
-
Truck scales and heavy-capacity weighing systems
-
Industrial and agricultural equipment weighing
The PLSB-25K load cell offers rugged reliability, environmental protection, and accurate weight measurement for demanding industrial applications. Whether installed in Rice Lake mount assemblies or custom systems, this load cell is built for precision and durability.
Contact us today to request a quote or learn how the PLSB-25K can enhance your weighing operations.
