| Power Input |
|
12 to 24 VDC, 5 W |
| Power Consumption |
|
70 mA min to 100 mA max |
| Excitation Voltage |
|
5V, 120 mA, 16 × 350 ohm load cells |
| Analog Signal Input Range |
|
± 39 mV |
| Analog Signal Sensitivity |
|
High resolution: 0.01 µV/d, Legal for trade: 0.3 µV/e |
| A/D Sample Rate |
|
Up to 4800 Hz |
| Resolution |
|
Internal: 1,500,000 counts, Display: 800,000 |
| Legal for Trade Divisions |
|
Up to 10,000 e or multi-field 2 × 3,000 e |
| Digital I/O |
|
2 configurable inputs (12-24 VDC), 4 configurable outputs (150 mA 48 VAC/150 mA 60 VDC) |
| Communication Ports |
|
(1) RS-485, (1) RS-232, (1) Micro-USB |
| Serial Port Update Rate |
|
Up to 1600 Hz |
| Fieldbus Update Rate |
|
Up to 120 Hz |
| Analog Output (if equipped) |
|
Opto-isolated, 16-bit (0-20 mA, 4-20 mA, 0-5 VDC, 0-10 VDC) |
| Annunciators |
|
Net, center of zero, stability |
| Display |
|
Six-digit (8 mm), red LED |
| Keys/Buttons |
|
Five-key membrane panel (Zero, Tare, Mode, Print, C) |
| Dimensions (L × W × H) |
|
4.72 × 0.9 × 4.0 in (120 × 23 × 112 mm) |
| Operating Temperature |
|
-4 °F to 140 °F (-20 °C to 60 °C) |
| Certified Temperature |
|
14 °F to 104 °F (-10 °C to 40 °C) |
| Humidity |
|
85% non-condensing |
| Enclosure Rating |
|
ABS plastic |
| Warranty |
|
One-year limited |
| Approvals |
|
CE-M EN 45501, 2014/30/EU EMC, 2014/35/EU LVD, 2011/65/EU RoHS, OIML R61 - MID, OIML R76 |
